Button Parameters:

• P0 = (Heat / Cool) sets whether the relay is energized or de-energized when trigger temperature is reached.
• P1 = (Hysteresis) sets the difference in degrees between the Trigger temp and when the relay changes state
• P2 = (Max Temp) sets the maximum Trigger temp that can be set
• P3 = (Min Temp) sets the minimum Trigger temp that can be set
• P4 = (Temp Correction) sets an offset to use for the displayed value
• P5 = (Delay) sets a time delay between when the Trigger temp is reached and when the relay is switched
• P6 = (Alarm) sets a high temperature ‘alarm’ trip point
