Features :
- Comparably more powerful than NEMA17 motors.
- Input pulse decides the rotation angle of the motor.
- High accuracy of around 3 to 5% a step.
- Provides good starting, stopping and reversing.
- Control of this motor is less costly because of exclusion of complex control circuitry.
- The speed is proportional to the frequency of the input pulses.
Specifications:
| Step Angle |
1.8 degree |
| Holding Torque (Kg-Cm) |
7.2 |
| Operating Voltage (VDC) |
6.6 |
| Supply Current (A) |
1A |
| No. of Leads |
6 |
| Inductance (mH/Phase) |
8.2 |
| Resistance |
6.6 ohms |
| Rotor Inertia (gm-cm2) |
275 |
| Weight (gm) |
600 |
| Dimensions (mm) LxWxH |
57 x 57 x 52 |
| Detent Torque (kg-cm) |
0.36 |
| Frame Size (mm) |
57 x 57 |
| Inductance Accuracy |
±20% |
| Resistance Accuracy |
±10% |
| Shaft Type |
Round |
| Shaft Diameter (mm) |
6.35 |
| Shaft Length (mm) |
20.6 |
| Step Angle Accuracy |
±5% |
| Cable Length (cm) |
30 |
