Features :
- Comparably more powerful than NEMA17 motors.
- Input pulse decides the rotation angle of the motor.
- High accuracy of around 3 to 5% a step.
- Provides good starting, stopping and reversing.
- Control of this motor is less costly because of exclusion of complex control circuitry.
- The speed is proportional to the frequency of the input pulses.
Specifications:
| Step Angle |
1.8 degree |
| Holding Torque (Kg-Cm) |
18.9 |
| Operating Voltage (VDC) |
3.2 |
| Supply Current (A) |
2.8 A/Phase |
| No. of Leads |
6 |
| Inductance (mH/Phase) |
3.6 |
| Resistance |
1.13 ohmss |
| Rotor Inertia (gm-cm2) |
480 |
| Weight (gm) |
900 |
| Dimensions (mm) LxWxH |
57x57x52 |
| Frame Size (mm) |
57 x 57 |
| Inductance Accuracy |
±20% |
| Resistance Accuracy |
10% |
| Shaft Diameter (mm) |
6.35 |
| Shaft Length (mm) |
20.6 |
| Step Angle Accuracy |
±5% |
| Cable Length (cm) |
30 |
