Features:
- Iron Body Material
- High quality ultra-compact electric lock.
- Rustproof, durable, safe, convenient to use.
- Suction which tightly sucks the iron, thus locking the door.
- Designed with the open frame type and mount board, high power.
- Easy to install for the electric door lock or other automatic door lock systems with the mounting board
- Applicable for being installed in the escape door or fire door electronic controlled system.
- Adopts the principle of electric magnetism, when the current through the silicon, the electromagnetic lock will achieve a strong.
Specifications:
| Model |
DC 12V 1A Solenoid Door Lock |
| Rated Operating Voltage (VDC) |
12 |
| Stroke |
10 mm |
| Rated Current (mA) |
1A |
| Holding Force (N) |
19 |
| Energized forms |
Intermittent |
| Cable Length (cm) |
20 |
| Operation Mode |
Normally Closed |
| Dimensions (mm) LxWxH |
64 x 26 x 20 |
| Weight(gm) |
108 |
