Application Examples:

• Automated Greenhouses

Automatically manage the humidity and temperature to ensure the best environment for crop growth, minimizing carbon emissions and increasing economic yield. The inclusion of an Arduino MKR GPS Shield allows for optimum crop rotation planning and acquisition of geospatial data.

• Hydroponics/Aquaponics

Since hydroponics involves the growth of plants without soil, delicate care must be taken to maintain the conditions required for optimum growth. The Arduino Edge Control can be set up to control these conditions with minimal manual labor. The Arduino Edge Control can help match the even higher requirements of Aquaponics, by providing automated control over the internal process and reducing production risks.

Features:

1. Precision farming & process automation.
2. Improved yield & lower production risks.
3. Real-time & historical data.
4. Monitors environmental conditions.
5. Powerable by solar panels.
6. Easy installation.
7. Connect easily with sensors/devices.
8. Operates in high & low temperatures.
9. Choice of connectivity types.
10. Supports TensorFlow Lite micro for tiny machine learning applications.

    Specifications :-

    Microcontroller	nRF52840
    Digital input	6 x edge-sensitive wake-up pins
    Digital Output	8 x latching relay command outputs with drivers 8 x latching relay command outputs without drivers
    Relays	4 x 60V/2.5A galvanically isolated solid-state relays
    Analog input	4 x 4-20 mA inputs 8 x 0-5v analog inputs 16 x hydrostatic watermark sensor input
    Terminal Block Connectors	6 x 18 pin plug-in terminal block connector
    Power Supply	12 V Acid/Lead SLA Battery Supply (Recharged via solar panels)
    Power Consumption	Low Power (up to 34 months on a 12v/5Ah battery) 200uA Sleep Current
    Memory	1 MB onboard Flash memory 2 MB onboard QSPI Flash memory
    Connectivity	Bluetooth Wifi 3G NB-IOT LoRaWAN
    Peripherals	Full-speed 12 Mbps USB Arm cryptoCell CC310 security subsystem QSPI/SPI/TWI/PDM/QDEC High speed 32 MHz SPI Quad SPI interface 32 MHz 12-bit 200 ksps ADC
    Operating Temperature Range (C)	-40 to 85
    Length (mm)	104
    Width (mm)	86
